DIN Rail Single Phase Electronic Energy Meter

1. Product Overview

The DIN-Rail Single Phase Electronic Energy Meter is a new-generation measuring instrument designed for precise active energy tracking. Adopting advanced micro-electronics, large-scale integrated circuits, and SMT manufacturing techniques, this meter guarantees excellent reliability and long-term stability. Fully compliant with IEC62053-21 (Class 1) standards, it features bi-directional measurement, making it capable of accurately recording both positive and reverse energy flows. With its compact footprint, it is widely used in residential sub-metering, commercial facilities, and renewable energy systems.

2. Six Key Features

• Class 1 High Accuracy: Built with advanced digital sampling technology, ensuring precise energy measurement in compliance with GB/T17215.321-2008 and IEC62053-21 international standards.

• Bi-Directional Measurement: Intelligently detects and measures both positive and reverse active energy consumption, ideal for grid-tied solar or complex power systems.

• Dual Energy Tracking (Resettable): Selected models feature a smart dual-display system. Users can view the Total Electricity (non-resettable for billing security) and Temporary Electricity (which can be reset to zero via the front button).

• Multiple Model Variations: Available in various widths (from ultra-compact 18mm to standard 35mm and up) to perfectly fit any distribution box requirement.

• Optional RS485 Communication: Specific models (e.g., DDS661, DDS669) can be equipped with an RS485 port for seamless data transmission to centralized management systems.

• Smart Indicator Lights: Features an impulse indicator (flashes for 80ms to indicate energy usage) and a dedicated reverse direction warning light for easy troubleshooting.

3. Technical Specifications

4. Application Scenarios

• Tenant & Apartment Sub-Metering: Provides reliable, tamper-proof total kWh readings for landlords to bill tenants accurately.

• Solar PV Systems: The bi-directional measurement capability perfectly handles the energy flow in grid-tied solar inverter applications.

• Commercial Facilities: Compact 18mm/35mm designs save maximum space in crowded distribution boards for offices and retail stores.

5. FAQ (Frequently Asked Questions)

Q1: Can I reset the kWh reading on this meter?

A: It depends on the model. Models equipped with a front button feature a “Dual Energy” display. You can reset the Temporary Electricity by pressing and holding the “RESET” button for 3-5 seconds. However, for security and billing integrity, the Total Electricity cannot be reset. Models without a button cannot be reset.

Q2: What does the “Reverse Direction” indicator light mean?

A: If the reverse direction indicator lights up, it means the electrical load is connected in reverse (the current is flowing backward). The meter will still accurately measure this reverse energy, but you should check your L (Live) and N (Neutral) wiring connections.

Q3: Does this meter support remote data reading?

A: Yes, specific models within this series (such as Model 1 / DDS661 and Model 3 / DDS669) can be customized with an RS485 communication interface for remote reading and integration into smart management systems.

Q4: Is the meter suitable for outdoor use?

A: This meter is designed for indoor installation. If it needs to be installed outdoors, or in dusty/humid environments, it must be placed inside a protective, weatherproof distribution box to prevent mechanical or environmental damage.

Q5: What is the warranty period for this product?

A: We offer an 18-month warranty from the date of manufacture. As long as the factory seal remains intact and it is operated within the specified requirements, we guarantee reliable performance.
